- Place of Origin: Made In China
- Brand Name: ECHU
- Model Number: H03VVH2-F
Application: Used as an indoor general wiring cable primarily for installations in public areas. Examples include use on pendant lighting drops or as a general supply lead.
Standards: BS6500
Conductor: Class 5 flexible plain copper conductor to BS EN 60228:2005 (previously BS6360)
Insulation: PVC (Polyvinyl Chloride) TI2 to BS7655
Sheath: PVC (Polyvinyl Chloride) TM2 to BS7655
Sheath Colour: Black or White
Voltage Rating: 300/300V
Temperature Rating:0ºC to 70ºC
Minimum Bending Radius: 6 x overall diameter
H03VVH2-F,2192Y Flexible Cable to BS6500
| No. of Cores x Nominal Cross Sectional Area # x mm² | Nominal Overall Diameter mm |
|---|---|
| 2 x 0.50 | 3.10 x 5.00 |
| 2 x 0.75 | 3.30 x 5.40 |
